FNIRSI DSO-152 200KHz 2.5MS/s Mini Pocket Handheld Digital Oscilloscope
SKU:
TLS-QC5802
Availability:
Out Of Stock
-
- Rs. 2,540.00
- Unit price
- per
Subtotal:
Rs. 2,540.00
Description
xFNIRSI® DSO-152 200KHz 2.5MS/s Mini Pocket Handheld Digital Oscilloscope is a compact and portable digital oscilloscope designed for electronics maintenance, educational laboratories, DIY projects, and basic signal analysis. Featuring a 2.5MS/s sampling rate, 200KHz bandwidth, one-key AUTO calibration, and a rechargeable battery, it provides an easy-to-use solution for waveform observation and troubleshooting.
FNIRSI® DSO-152 200KHz Mini Pocket Handheld Digital Oscilloscope Datasheet
Features:
- Compact Pocket-Sized Design
- 200KHz Bandwidth Oscilloscope
- 2.5MS/s Real-Time Sampling Rate
- One-Key AUTO Waveform Detection
- Full Trigger Functions (Auto, Normal, Single)
- 2.8-Inch TFT LCD Display
- AC and DC Coupling Support
- Type-C Charging Interface
- Built-in Rechargeable Lithium Battery
- Fast Baseline Calibration Function
- Suitable for Analog and Digital Signals
- Lightweight and Portable Design
Specifications:
| Parameter | Value |
|---|---|
| Brand | FNIRSI® |
| Model | DSO-152 |
| Product Type | Digital Oscilloscope |
| Channels | 1 |
| Display Size | 2.8 Inch TFT LCD |
| Display Resolution | 320 × 240 Pixels |
| Sampling Rate | 2.5MS/s |
| Bandwidth | 200KHz |
| Vertical Sensitivity | 10mV/Div ~ 20V/Div |
| Time Base Range | 10μs/Div ~ 50s/Div |
| Voltage Range (X1 Probe) | ±40V (80Vpp) |
| Voltage Range (X10 Probe) | ±400V (800Vpp) |
| Trigger Mode | Auto / Normal / Single |
| Coupling Method | AC / DC |
| Square Wave Calibration Frequency | 1kHz |
| Square Wave Duty Cycle | 50% |
| Battery Capacity | 1000mAh Lithium Battery |
| Charging Interface | USB Type-C |
| Charging Input | 5V / 1A |
| Operating Time | Up to 4 Hours |
| Dimensions | 99 × 68.3 × 19.5 mm |
| Weight | 100 g |
Explore the FNIRSI Collection featuring advanced digital multimeters, oscilloscopes, signal generators, laser rangefinders, thermal cameras, USB testers, and precision electronic test equipment. Ideal for electronics engineers, technicians, makers, DIY enthusiasts, troubleshooting, circuit analysis, industrial maintenance, and professional measurement applications.
Also Check These Products:-
FNIRSI HRM-10 Battery Voltage Internal Resistance Tester
FNIRSI LCR-P1 Multifunction Transistor Capacitor Tester
FNIRSI LCR-ST1 Mini Smart Tweezer LCR SMD ESR Tester
FNIRSI DMC-100 DC AC Current Voltage Digital Clamp Multimeter
FNIRSI DMT-99 Intelligent Color Screen Digital MultiMeter
Package Includes:
1 x FNIRSI® DSO-152 200KHz 2.5MS/s Mini Pocket Handheld Digital Oscilloscope
