The A733 PNP Transistor - SOT-23 SMD Package is a general-purpose small-signal transistor designed for low-noise amplification and signal switching. With high gain, low saturation voltage, and stable operation, it’s ideal for use in audio amplifiers, signal processing, and low-power switching circuits.
Features:
- High DC current gain for reliable amplification
- Low collector-emitter saturation voltage
- Low noise figure for clean signal performance
- Compact SOT-23 surface-mount package
- Wide operating temperature range for versatile use
Specifications:
- Collector-Base Voltage (VCBO): -60V
- Collector-Emitter Voltage (VCEO): -50V
- Emitter-Base Voltage (VEBO): -5V
- Collector Current (IC): -150mA
- Power Dissipation (PC): 200mW
- Thermal Resistance Junction-to-Ambient (RθJA): 625°C/W
- Operating Junction and Storage Temperature Range (TJ, TSTG): -55°C to +150°C
- Collector-Base Breakdown Voltage (V(BR)CBO): -60V
- Collector-Emitter Breakdown Voltage (V(BR)CEO): -50V
- Emitter-Base Breakdown Voltage (V(BR)EBO): -5V
- Collector Cutoff Current (ICBO): -100nA
- Emitter Cutoff Current (IEBO): -100nA
- DC Current Gain (hFE) at VCE = -6V, IC = -1mA: 120 to 475
- Collector-Emitter Saturation Voltage (VCE(sat)) : -0.18V to -0.3V
- Base-Emitter Voltage (VBE(ON)): -0.58V to -0.68V
- Transition Frequency (fT): 80MHz
- Output Capacitance (Cob): 4.5 to 7pF
- Noise Figure (NF): 6 to 20dB
Package Includes:
10 × A733 PNP Transistor - SOT-23 SMD Package
