UNI-T UT61B+ Digital Multimeter True RMS AC/DC Voltage Current Resistance Capacitance Tester

Brand: UNI-T
SKU: TLS-QC5832
Availability: 10 In Stock
Rs. 4,290.00
Subtotal: Rs. 4,290.00
Description
Description
x

UNI-T UT61B+ Digital Multimeter True RMS AC/DC Voltage Current Resistance Capacitance Tester is a professional True RMS digital multimeter designed for accurate electrical measurements in industrial maintenance, electronics troubleshooting, laboratory testing, and field service applications. Featuring a 6000-count display, CAT III 1000V/CAT IV 600V safety rating, USB communication, NCV detection, and comprehensive measurement functions, it provides reliable performance for both professionals and enthusiasts.

UNI-T UT61B+ Digital Multimeter Current Resistance Capacitance Tester Datasheet

Features:

  1. True RMS Measurement Technology
  2. 6000 Count High-Resolution Display
  3. Measures up to 1000V AC/DC
  4. CAT III 1000V / CAT IV 600V Safety Rating
  5. Auto and Manual Range Selection
  6. USB Data Communication Support
  7. Maximum and Minimum Value Recording
  8. Relative Measurement Mode
  9. Analog Bar Graph Display
  10. Non-Contact Voltage (NCV) Detection
  11. Diode and Continuity Testing
  12. Frequency and Duty Cycle Measurement
  13. High Voltage Alarm Function
  14. Auto Power Off Function
  15. LCD Backlight Display


Specifications:

Parameter Value
Brand UNI-T
Model UT61B+
Product Type True RMS Digital Multimeter
Display Count 6000
Safety Rating CAT III 1000V / CAT IV 600V
AC Voltage Range 1000V ± (1% + 3)
DC Voltage Range 1000V ± (0.5% + 3)
AC Current Range 10A ± (1.2% + 5)
DC Current Range 10A ± (1% + 2)
Resistance Range 60MΩ ± (1% + 2)
Capacitance Range 60mF ± (3% + 5)
Frequency Range 10MHz ± (0.1% + 4)
Duty Cycle Range 0.1% ~ 99.9%
Bandwidth 40Hz ~ 500Hz
Analog Bar Graph 31 Segments
Range Selection Auto / Manual
Data Hold Supported
Relative Mode Supported
Maximum / Minimum Recording Supported
USB Communication Supported
NCV Detection Supported
Diode Test Supported
Continuity Test Supported
Backlight Display Supported
Low Battery Indication Supported
High Voltage Alarm Supported
Auto Power Off Supported
Length 190 mm
Width 90 mm
Weight 350 g



If you are looking for more UNI-T products like Oscilloscope Multimeters visit the collection of products for your electronic projects.

Also Check These Out:-

UNI-T UT60EU Digital Multimeter 1000V AC DC Voltage Current Meter

UNI-T UT33D+ Original Palm Size Digital Multimeter

UNI-T UT33D+ Digital Palm Size Multimeter

Package Includes:

1 x UNI-T UT61B+ Digital Multimeter

1 x Test Lead Set

1 x USB Cable

1 x User Manual
