WS2812B SMD2020 Addressable RGB Pixel LED - SMD Package

The WS2812B SMD2020 is a compact, intelligent, addressable RGB LED that integrates a control circuit and RGB chip into a single SMD package. Designed for ultra-small form factor applications, it features high brightness and consistent color output with individual digital control. Each LED has a built-in driver IC, enabling precise control over color and brightness via a single data line, making it perfect for wearable devices, fine-pitch LED displays, and decorative lighting effects.

Features of WS2812B SMD2020 Addressable RGB LED:

1. Ultra-small SMD2020 package ideal for high-density installations
2. Integrated driver IC with data reshaping and amplification
3. Full 24-bit color control per pixel (8-bit each for R, G, B)
4. Requires only one data line for control
5. Chainable for creating dynamic lighting effects
6. Compatible with popular microcontrollers and LED libraries (e.g., FastLED, Adafruit NeoPixel)
7. Long lifespan and low power consumption

Specifications of WS2812B SMD2020 Addressable RGB LED:

• LED Type: RGB Addressable
• IC Type: WS2812B Built-in
• Package: SMD2020
• Operating Voltage: 5V DC
• Color Depth: 24-bit (8-bit per channel)
• Data Protocol: One-wire UART-like protocol
• Refresh Rate: Up to 800 Kbps
• View Angle: 120°
• Operating Temperature: -20°C to +60°C

Package Includes:

1 × WS2812B SMD2020 Addressable RGB Pixel LED
