PIC16F676 Microcontroller PIC16F676 Microcontroller

QC0057

27 In stock

Rs. 83.00
-
+
Rs. 83.00
(inc. GST)
[Delivery: 2 to 5 days]

PIC16F676 is powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS Flash-based 8-bit microcontroller packs Microchip’s powerful PIC® MCU architecture into a 14-pin package and features 8 channels for the 10-bit Analog-to-Digital (A/D) converter, 1 comparator and 128 bytes of EEPROM data memory. This device is easily adapted for automotive, industrial, appliances and consumer entry-level product applications that require field re-programmability.

It has 128 bytes of EEPROM and 64 Bytes of SRAM. For debugging and Programming, it has an ICD2 interface with optional header adapter. The Pull-up state of the pins can be programmed to decrease additional resistor counts in applications.



PIC16F676 pinout:

PIC16F676 pinout



PIC16F676 Specifications

Specification

  1. 128 bytes of EEPROM Data Memory
  2. Programmable pull-up resistors
  3. Individually selectable analog channels
  4. ICD2 programming support or debugging support with optional header adapter
  5. 8 oscillator selections including precision 4 MHz RC oscillator with programmable calibration and Power-on Reset
  6. Program Memory Type: Flash
  7. Program Memory (KB): 1.75
  8. CPU Speed (MIPS): 5
  9. RAM Bytes:64
  10. Data EEPROM (bytes): 128
  11. Digital Communication Peripherals:1-UART,
  12. Timers:1 x 8-bit, 1 x 16-bit
  13. ADC:8 ch, 10-bit
  14. Comparators:1
  15. Temperature Range (C): -40 to 125
  16. Operating Voltage Range (V): 2 to 5.5
  17. Pin Count: 14
  18. Cap Touch Channels: 8

PIC16F676 Applications:

  • Analog to Digital conversion
  • Data processing
  • Small control projects
  • Logic devices
  • Small Industrial applications



PIC16F676 Dimension and footprint:

PIC16F676

Example Projects on PIC16F676:

Introduction to PIC16F676

Additional Resources:

PIC16F676 Datasheet


Package Contains

1x PIC16F676

PIC16F676 is powerful (200 nanosecond instruction execution) yet easy-to-program (only 35 single word instructions) CMOS Flash-based 8-bit microcontroller packs Microchip’s powerful PIC® MCU architecture into a 14-pin package and features 8 channels for the 10-bit Analog-to-Digital (A/D) converter, 1 comparator and 128 bytes of EEPROM data memory. This device is easily adapted for automotive, industrial, appliances and consumer entry-level product applications that require field re-programmability.

It has 128 bytes of EEPROM and 64 Bytes of SRAM. For debugging and Programming, it has an ICD2 interface with optional header adapter. The Pull-up state of the pins can be programmed to decrease additional resistor counts in applications.



PIC16F676 pinout:

PIC16F676 pinout



PIC16F676 Specifications

Specification

  1. 128 bytes of EEPROM Data Memory
  2. Programmable pull-up resistors
  3. Individually selectable analog channels
  4. ICD2 programming support or debugging support with optional header adapter
  5. 8 oscillator selections including precision 4 MHz RC oscillator with programmable calibration and Power-on Reset
  6. Program Memory Type: Flash
  7. Program Memory (KB): 1.75
  8. CPU Speed (MIPS): 5
  9. RAM Bytes:64
  10. Data EEPROM (bytes): 128
  11. Digital Communication Peripherals:1-UART,
  12. Timers:1 x 8-bit, 1 x 16-bit
  13. ADC:8 ch, 10-bit
  14. Comparators:1
  15. Temperature Range (C): -40 to 125
  16. Operating Voltage Range (V): 2 to 5.5
  17. Pin Count: 14
  18. Cap Touch Channels: 8

PIC16F676 Applications:

  • Analog to Digital conversion
  • Data processing
  • Small control projects
  • Logic devices
  • Small Industrial applications



PIC16F676 Dimension and footprint:

PIC16F676

Example Projects on PIC16F676:

Introduction to PIC16F676

Additional Resources:

PIC16F676 Datasheet


Package Contains

1x PIC16F676
