PAM8610 Class-D Audio Amplifier Board PAM8610 Class-D Audio Amplifier Board

QC0821

4 In stock

Rs. 111.00
-
+
Rs. 111.00
(inc. GST)
[Delivery: 2 to 5 days]

The PAM8610 is a stereo Class-D audio amplifier with DC Volume Control. It offers 15W (per channel) output with low THD+N (0.1%), low EMI, and good PSRR thus high-quality sound reproduction. It has 32 steps DC volume control with a range of +32dB to -75dB. The PAM8610 supports 7V to 15V supply. It is more efficient than competitors’ ICs or products. It also has an inbuilt mute switch option as a pinout on the board.



PAM8610 pinout:

PAM8610 pinout



Specifications

  1. PAM8610 as main driver IC
  2. Dual-Channel Stereo Output
  3. MAX Wattage: 15W
  4. Input Voltage Range:  7V to 15V power Supply
  5. Volume control resolution: 32 Steps
  6. Volume control range: +32dB to -75dB
  7. Working Mode: Class D (PWM modulation type).
  8. Much higher efficiency in terms of cost and performance than competitors’ ICs
  9. This plate with a switching function, SW short, will turn off the power amplifier.
  10. No External Heat Sink Required


PAM8610 Dimension and footprint:

PAM8610-Dimension

PAM8610 Applications:

  • Portable Audio Player
  • Mini Speaker Control System
  • Music Systems
  • Radio or TV
  • Power Amplifier


Example Projects on PAM8610:

Detailed Info about PAM8610 Module

Additional Resources:

PAM8610  Datasheet


Package Contains

1x PAM8610 audio module

The PAM8610 is a stereo Class-D audio amplifier with DC Volume Control. It offers 15W (per channel) output with low THD+N (0.1%), low EMI, and good PSRR thus high-quality sound reproduction. It has 32 steps DC volume control with a range of +32dB to -75dB. The PAM8610 supports 7V to 15V supply. It is more efficient than competitors’ ICs or products. It also has an inbuilt mute switch option as a pinout on the board.



PAM8610 pinout:

PAM8610 pinout



Specifications

  1. PAM8610 as main driver IC
  2. Dual-Channel Stereo Output
  3. MAX Wattage: 15W
  4. Input Voltage Range:  7V to 15V power Supply
  5. Volume control resolution: 32 Steps
  6. Volume control range: +32dB to -75dB
  7. Working Mode: Class D (PWM modulation type).
  8. Much higher efficiency in terms of cost and performance than competitors’ ICs
  9. This plate with a switching function, SW short, will turn off the power amplifier.
  10. No External Heat Sink Required


PAM8610 Dimension and footprint:

PAM8610-Dimension

PAM8610 Applications:

  • Portable Audio Player
  • Mini Speaker Control System
  • Music Systems
  • Radio or TV
  • Power Amplifier


Example Projects on PAM8610:

Detailed Info about PAM8610 Module

Additional Resources:

PAM8610  Datasheet


Package Contains

1x PAM8610 audio module
