MBR30100FCT 100V 30A Dual Schottky Rectifier - TO-220F DIP Package is a high-performance dual common cathode Schottky barrier rectifier designed for switching power supplies, DC-DC converters, battery chargers, solar inverters, freewheeling circuits, and power management applications. Featuring a 100V reverse voltage rating, 30A average forward current, low forward voltage drop, and fast switching characteristics, it delivers excellent efficiency, reduced power loss, and reliable operation in high-frequency power circuits.
| Parameter | Value |
|---|---|
| Product Type | Dual Schottky Barrier Rectifier |
| Model | MBR30100FCT |
| Diode Configuration | Dual Common Cathode |
| Average Forward Current (IF(AV)) | 30A |
| Forward Current (Per Diode) | 15A |
| Peak Repetitive Reverse Voltage (VRRM) | 100V |
| DC Blocking Voltage | 100V |
| RMS Reverse Voltage | 70V |
| Peak Surge Forward Current (IFSM) | 200A |
| Forward Voltage (VF) | 1.0V Max @ 15A |
| Reverse Leakage Current (IR) | 100µA Max @ 100V |
| Power Dissipation | 2W |
| Junction Temperature | 125°C Max |
| Storage Temperature | -55°C to +150°C |
| Package Type | TO-220F (Full Pack) |
| Mounting Type | Through Hole (DIP) |
| Polarity | Common Cathode |
| Compliance | RoHS |
