Honeywell SS360NT Board Mount Hall Effect/Magnetic Sensor IC - SOT-23-3 SMD Package

Honeywell SS360NT Board Mount Hall Effect/Magnetic Sensor IC is a bipolar latching Hall-effect magnetic sensor designed for accurate magnetic field detection and digital switching, featuring low power consumption, high sensitivity with defined operate and release points, SMD SOT-23-3 packaging for compact PCB designs, and reliable performance across a wide voltage and temperature range, making it ideal for position sensing, proximity detection, speed sensing, and industrial automation applications.

Features:

1. Bipolar latching Hall-effect sensing technology
2. Low operating supply current of 3.5 mA
3. High output current capability up to 20 mA
4. Defined magnetic operate and release points
5. Wide operating voltage support up to 24 V
6. Surface-mount SOT-23-3 compact package
7. Designed for reliable industrial and automotive use

Specifications:

• Product Type: Board Mount Hall Effect / Magnetic Sensor
• Type: Bipolar
• Operating Supply Voltage: 24 V
• Operating Supply Current: 3.5 mA
• Maximum Output Current: 20 mA
• Operating Point: 5 G to 55 G
• Release Point: -55 G to -5 G
• Output Voltage: -500 mV to 26 V
• Mounting Type: SMD / SMT
• Package Type: SOT-23-3
• Operating Temperature Range: -40 °C to +150 °C
• Unit Weight: 63 mg
• Applications: Proximity sensing, position detection, speed sensing, magnetic field detection, motor control, industrial automation

Package Includes:

1 × Honeywell SS360NT Board Mount Hall Effect/Magnetic Sensor IC - SOT-23-3 SMD Package
