ESP32 Camera Development Board WiFi+Bluetooth Module with OV2640 Camera Module ESP32 Camera Development Board WiFi+Bluetooth Module with OV2640 Camera Module

QC0750

50 In stock

Rs. 699.00
-
+
Rs. 699.00
(inc. GST)
[Delivery: 2 to 5 days]

The ESP32-CAM is an Original ESP32 CAM WiFi+Bluetooth module board along with OV2640 Camera Module. This product is based on the ESP32 chip with the additional facility of using a camera. That means, the features of ESP32, especially the Bluetooth and the WiFi connectivity is available along with an additional peripheral OV2640 camera module. This opens up a lot of applications and usage in the field of various IoT applications

For the camera spec, it is a very small sized camera yet powerful that can be used with minimum system supports. It is available in a ribbon cable formation. The camera is powered by an UXGA resolution of 1600 x 1200 resolution with 2.0 Megapixel resolution. It is a good choice for most of the camera based IoT applications.


ESP32 Board & OV2640 Camera Module pinout:

ESP32 Camera DEVELOPMENT BOARD Pinout

Package Contains

1x ESP32 Board & OV2640 Camera Module



ESP32 Camera Development Board and OV2640 features & Specifications:

  • ESP32-CAM Board and OV2640 Camera module in two separate parts
  • 9 fully customizable I/O ports
  • 32Mbit Flash
  • 520KB SRAM +4M PSRAM
  • 802.11 b/g/n/e/i WiFi support
  • 4.2v Bluetooth support
  • IPEX and PCB Antenna available
  • 3.6V ~ 5V supply voltage
  • 2.0 Megapixel Color CMOS UXGA technology
  • 8-bit compressed data output with RGB565/555 support
  • UXGA/SXGA at 15 fps
  • SVGA at 30 fps
  • CIF at 60 fps
  • 1600 x 1200 resolution of UXGA
  • 3590um x 2684um image area.

ESP32 WiFi and Bluetooth Module Applications:

  • Cellular or Camera Phone
  • IoT based surveillance camera
  • Web Cam
  • Image processing
  • Digital still camera
  • PC multimedia



ESP32 Board & OV2640 Camera Module Dimension and footprint:

ESP32 Camera DEVELOPMENT BOARD WIFI+BLUETOOTH WITH OV2640 CAMERA



Example Projects on ESP32 Board & OV2640 Camera Module:

ESP32 - video streaming and face recognition

Additional Resources:

ESP32 Board & OV2640 Camera Module Datasheet
