ES1J Super Fast recovery Rectifier Diode - DO-214AC SMD Package (Pack of 10)
SKU:
SMD-QC3731
Availability:
199
In Stock
- Rs. 13.00
- Rs. 13.00
- Unit price
- per
Subtotal:
Rs. 13.00
Description
xThe ES1J Super Fast recovery Rectifier Diode - DO-214AC SMD Package is designed for efficient AC to DC rectification in compact surface-mount applications. Its glass passivated chip junction delivers stable performance with fast recovery time, low losses, and high surge capability. Ideal for high-frequency power supplies, converters, and automated assembly circuits.
Features:
- Low profile DO-214AC package ideal for automated placement
- Glass passivated chip junction for long-term reliability
- Ultrafast 35 ns reverse recovery for high-efficiency switching
- High forward surge capability with high-temperature soldering tolerance
Specifications:
- Maximum Repetitive Peak Reverse Voltage (VRRM): 600 V
- Maximum RMS Voltage (VRMS): 420 V
- Maximum DC Blocking Voltage (VDC): 600 V
- Average Forward Rectified Current (IF(AV)): 1.0 A
- Peak Forward Surge Current (IFSM): 30 A
- Instantaneous Forward Voltage (VF) at 1 A: 1.70 V
- Reverse Current (IR) at 25°C: 5 µA
- Reverse Current (IR) at 125°C: 50 µA
- Reverse Recovery Time (trr): 35 ns
- Typical Junction Capacitance (CJ): 15 pF
- Thermal Resistance Junction to Lead (RθJL): 35 °C/W
- Operating and Storage Temperature Range (TJ, TSTG): -55°C to +150°C
Package Includes:
10 pcs × ES1J Super Fast recovery Rectifier Diode - DO-214AC SMD Package
