DTMF Decoder Module with Audio Receiver IC DTMF Decoder Module with Audio Receiver IC

QC0449

14 In stock

Rs. 150.00 Rs. 119.00
-
+
Rs. 119.00
(inc. GST)
[Delivery: 2 to 5 days]

The DTMF (Dual Tone Multi-Frequency) decoder module is commonly used to control robots with a mobile phone, it is also used in different kinds of home automation projects where mobile dial pad input is required. This module works as a tone decoder that uses its 3.5 mm audio connector socket to get the input audio signal. The DTMF in tone based dial pads which produces a unique combination of two separate sine waves which can be decoded and produced as binary output. This module can produce binary output by getting tone input from 0-9 number, A - D letters, * and # symbols. It is popularly used for mobile and fixed telephone voice dialing and recording related functions.



Specifications

  • Power Input: 5V Nominal (4.5V - 5.5V)
  • Onboard 3.5mm jack input Facility
  • MT8870 Based Frequency Decoder
  • 5 Channel Interface
  • Detects 0-9, A-D, *, #
  • LED notifier for Output state
  • 54” Pin pitch



Product Description

DTMF-Decoder-Module

Additional Resources

Receiver IC Datasheet

DTMF Controlled Robot using Arduino



Package Content

1×DTMF Decoder Module

1x Audio Receiver IC

The DTMF (Dual Tone Multi-Frequency) decoder module is commonly used to control robots with a mobile phone, it is also used in different kinds of home automation projects where mobile dial pad input is required. This module works as a tone decoder that uses its 3.5 mm audio connector socket to get the input audio signal. The DTMF in tone based dial pads which produces a unique combination of two separate sine waves which can be decoded and produced as binary output. This module can produce binary output by getting tone input from 0-9 number, A - D letters, * and # symbols. It is popularly used for mobile and fixed telephone voice dialing and recording related functions.



Specifications

  • Power Input: 5V Nominal (4.5V - 5.5V)
  • Onboard 3.5mm jack input Facility
  • MT8870 Based Frequency Decoder
  • 5 Channel Interface
  • Detects 0-9, A-D, *, #
  • LED notifier for Output state
  • 54” Pin pitch



Product Description

DTMF-Decoder-Module

Additional Resources

Receiver IC Datasheet

DTMF Controlled Robot using Arduino



Package Content

1×DTMF Decoder Module

1x Audio Receiver IC
