Double BTS7960 43A H-Bridge High-Power Stepper Motor Driver Module

The Double BTS7960 43A H-Bridge High-Power Stepper Motor Driver Module is a robust motor control solution designed for driving high-current DC motors and stepper motors with precise speed and direction control. Built around dual BTS7960 high-current H-bridge driver ICs, this module provides stable bidirectional control, high efficiency, and strong protection features, making it ideal for robotics, automation systems, CNC machines, and electric vehicle applications.

The module supports PWM speed control and logic-level input from microcontrollers such as Arduino, Raspberry Pi, and PLC systems. Its high current handling capability ensures smooth operation even under heavy load conditions, while integrated protection circuits enhance safety and reliability.

Features:

1. Dual BTS7960 H-bridge driver design for high power applications
2. Supports motor currents up to 43A (peak)
3. Bidirectional motor control (forward and reverse)
4. PWM speed control support
5. High efficiency with low heat generation
6. Built-in overcurrent and thermal protection
7. Compatible with Arduino, Raspberry Pi, and microcontrollers
8. Ideal for DC motors and stepper motor applications
9. Strong screw terminals for secure power and motor connections
10. Stable performance for heavy-duty automation systems

Specifications:

• Module Type: Double H-Bridge Motor Driver
• Driver IC: BTS7960 (Dual Configuration)
• Maximum Peak Current: 43A
• Continuous Current: Up to 25A (with adequate cooling)
• Operating Voltage: 6V – 27V DC
• Control Signal Level: 3.3V – 5V TTL Compatible
• PWM Frequency: Up to 25kHz
• Motor Type Supported: DC Motors / Stepper Motors
• Control Mode: PWM + Direction Control
• Logic Isolation: Yes
• Protection Features:

• • Overcurrent Protection

  • Over-temperature Protection

  • Short Circuit Protection

• Operating Temperature: -20°C to +85°C
• Mounting Type: PCB Module with screw terminals
• Heatsink: Integrated / External cooling recommended for high loads

Package Includes:

1 × Double BTS7960 43A H-Bridge High-Power Motor Driver Module
