CD4022BE Texas Instruments 3V to 18V Decade Counter / Divider IC - DIP-16
CD4022BE Texas Instruments 3V to 18V Decade Counter / Divider IC - DIP-16

Free Shipping

Free standard shipping on all orders over INR 500

COD Available

On all the orders above INR 500

Free Returns

*Terms & Conditions Applied

Customer Assistance

Contact Us : 0141-4946677 or support@quartzcomponents.com

CD4026 Decade Counter/Divider IC - DIP-16 Package

Brand: GENERIC
SKU: CMP-QC3257
Availability: 450 In Stock
Rs. 30.00
Subtotal: Rs. 30.00
Description
Description
x

The CD4026 is a CMOS Decade Counter/Divider IC with decoded 7-segment display outputs. It integrates a 5-stage Johnson decade counter and an output decoder capable of driving 7-segment numeric displays directly. This makes it ideal for digital clocks, frequency counters, and any application that requires counting and visual display.

Packaged in a standard DIP-16 format, the CD4026 is easy to use on breadboards and through-hole PCBs, making it perfect for prototyping and educational purposes.

Features of CD4026 Decade Counter IC:

  1. Counts from 0 to 9 (decade count)
  2. Direct drive for 7-segment LED display
  3. Synchronous clock input with ripple-free counting
  4. Automatic carry-out for cascading counters
  5. Clear and display enable functions
  6. Wide supply voltage range (3V to 15V)
  7. DIP-16 package for easy integration
  8. Low power consumption (CMOS technology)
  9. Ideal for digital clocks, event counters, timers, and LED display systems

Specifications of CD4026 IC:

  • Model: CD4026
  • Function: Decade Counter with 7-Segment Decoder
  • Supply Voltage: 3V to 15V
  • Typical Operating Voltage: 5V or 12V
  • Max Clock Frequency: ~6 MHz @ VDD = 10V
  • Package: DIP-16 – Through-Hole
  • Operating Temperature: -40°C to +85°C
  • Logic Family: CMOS

Package Includes:

1 × CD4026 Decade Counter/Divider IC – DIP-16 Package
