74HC541 Octal 3-State Buffer/Line Driver IC - DIP-20 Package

Brand: GENERIC
SKU: CMP-QC5962
Availability: 100 In Stock
Rs. 29.00
Subtotal: Rs. 29.00
Description
Description
x

74HC541 Octal 3-State Buffer/Line Driver IC - DIP-20 Package is a high-speed CMOS octal non-inverting buffer and line driver designed for bus-oriented applications requiring increased drive capability and signal isolation. It features eight non-inverting buffers with three-state outputs and two active-low output enable inputs, making it ideal for microprocessor systems, memory interfacing, digital communication, and data bus applications. The 74HC541 offers low power consumption, high noise immunity, and TTL-compatible inputs in a standard DIP-20 package.

Features:

  1. Octal Non-Inverting Buffer and Line Driver
  2. Three-State Outputs
  3. Two Active-Low Output Enable Inputs
  4. High-Speed CMOS Logic
  5. Low Power Consumption
  6. Wide Operating Voltage Range
  7. High Noise Immunity
  8. TTL Compatible Inputs
  9. High Output Drive Capability
  10. Suitable for Bus-Oriented Applications
  11. Reliable Signal Buffering and Isolation
  12. DIP-20 Through-Hole Package
  13. Ideal for Microprocessor and Memory Interfacing
  14. RoHS Compliant

Specifications:

Parameter Value
Product Type Octal 3-State Buffer/Line Driver IC
Model 74HC541
Logic Family 74HC CMOS
Package DIP-20
Number of Buffers 8 (Non-Inverting)
Output Type Three-State
Output Enable Dual Active-Low Enable Inputs
Supply Voltage (VCC) 2V to 6V
Logic Voltage 5V (Typical)
Propagation Delay 13ns (Typical @ 5V)
Output Drive Current ±7.8mA (Typical @ 5V)
Operating Temperature -40°C to +85°C
Mounting Type Through Hole
Applications Bus Drivers, Data Buffering, Memory Interfacing, Microprocessor Systems, Digital Communication, Signal Isolation
RoHS Compliance Yes



Pin Configuration:

Pin Function
1 OE1 (Output Enable 1, Active Low)
2 A0
3 Y0
4 A1
5 Y1
6 A2
7 Y2
8 A3
9 Y3
10 GND
11 Y4
12 A4
13 Y5
14 A5
15 Y6
16 A6
17 Y7
18 A7
19 OE2 (Output Enable 2, Active Low)
20 VCC
