12V Mini Hi-Fi PAM8610 Audio Stereo Amplifier Board 12V Mini Hi-Fi PAM8610 Audio Stereo Amplifier Board

QC0469

2 In stock

Rs. 390.00
-
+
Rs. 390.00
(inc. GST)

This is a Class D Audio Stereo Amplifier Board which you can use to drive two 10-15W speakers with high quality sound without much distortion and with high power efficiency. Class D amplifiers have a distinct advantage of higher gain and much lower power dissipation on class A, AB and B class amplifiers which results in the extended battery life in portable musical devices, less heat production and less space requirement. These features are a must in any portable device and since space and cooling is main concern in electronics this amplifier fits the bill perfectly. You can use it in your DIY audio output applications, any voice command action centre, small music players etc.

PAM8610 Audio Stereo Amplifier Board Specifications

  • D Class PAM8610 Audio Amplifier IC
  • Quiescent current: 20mA
  • Operating voltage: DC7.5 V- 15V
  • Rated output power: 10w + 10w (dual Speakers)
  • Frequency response: 20Hz to 50KHz
  • Recommended supply voltage: 12VDC

Product Description

12V Mini Hi-Fi PAM8610 Audio Stereo Amplifier Board

To use this module, you need to power the device via the DC jack given on the module and provide audio input through the 3.5mm audio Jack. Connect the Left and Right speakers by using the screw terminals and adjust the volume by the knob given on the module.

Package Contents

1×12V Mini Hi-Fi PAM8610 Stereo Board

This is a Class D Audio Stereo Amplifier Board which you can use to drive two 10-15W speakers with high quality sound without much distortion and with high power efficiency. Class D amplifiers have a distinct advantage of higher gain and much lower power dissipation on class A, AB and B class amplifiers which results in the extended battery life in portable musical devices, less heat production and less space requirement. These features are a must in any portable device and since space and cooling is main concern in electronics this amplifier fits the bill perfectly. You can use it in your DIY audio output applications, any voice command action centre, small music players etc.

PAM8610 Audio Stereo Amplifier Board Specifications

  • D Class PAM8610 Audio Amplifier IC
  • Quiescent current: 20mA
  • Operating voltage: DC7.5 V- 15V
  • Rated output power: 10w + 10w (dual Speakers)
  • Frequency response: 20Hz to 50KHz
  • Recommended supply voltage: 12VDC

Product Description

12V Mini Hi-Fi PAM8610 Audio Stereo Amplifier Board

To use this module, you need to power the device via the DC jack given on the module and provide audio input through the 3.5mm audio Jack. Connect the Left and Right speakers by using the screw terminals and adjust the volume by the knob given on the module.

Package Contents

1×12V Mini Hi-Fi PAM8610 Stereo Board
